Created attachment 34426 [details] Bad colors and expected ones. Bug description: In git master colours of toolbar icons (more noticeably) and other graphics are blurry or washed out. See attached screenshot. System environment: -- chipset: 855GM -- system architecture: 32-bit (i686) -- xf86-video-intel: 0c47195ca805881e3fbd5b9224be5c930feeeb8c (master up to March 24th) -- xserver: 1.7.6-1 -- mesa: 7.7-4 -- libdrm: 2.4.18-3 -- kernel: 2.6.33-4 -- Linux distribution: Debian unstable+experimental -- Machine or mobo model: Thinkpad R50e -- Display connector: LVDS Reproducing steps: 1. Install intel driver's master. 2. See funky colours. Additional info: After a git bisect, this commit turned out to be responsible. I reverted it on top of HEAD and indeed the problem was gone. commit d6b7f96fde1add92fd11f5a75869ae6fc688bf77 Author: Chris Wilson <chris@chris-wilson.co.uk> Date: Sat Mar 6 15:49:04 2010 +0000 Fill alpha on xrgb images. Do not try to fixup the alpha in the ff/shaders as this has the side-effect of overriding the alpha value of the border color, causing images to be padded with black rather than transparent. This can generate large and obnoxious visual artefacts. Fixes: Bug 17933 - x8r8g8b8 doesn't sample alpha=0 outside surface bounds http://bugs.freedesktop.org/show_bug.cgi?id=17933 and many related cairo test suite failures. Signed-off-by: Chris Wilson <chris@chris-wilson.co.uk> Side note: is there a test suite I can run? I usually use latest git master daily but I guess I could give you a more "scientific" hand if I run test suites also.
The commit that introduced this problem was made to fix bug #17933 so there are some comments in that bug report that might be useful here. -Carl
From bug 17933 we not that [server-side] fallback paths are not directly involved here, so it is not clear what the cause is. What I would like is a minimum gtk+ app that can be run as the solitary client of an X server so that I can trace the entire system and see what code paths are actually involved...
(In reply to comment #0) > Side note: is there a test suite I can run? I usually use latest git master > daily but I guess I could give you a more "scientific" hand if I run test > suites also. We don't have anything specific for the driver, but we often use other graphics-related test suites as standins, (for example cairo's test suite). But note that historically, our driver hasn't been able to pass cairo's test suite entirely. And fixing *that* was one of the motivating factors that led Chris to implement the fix that caused this regression. ;-) -Carl
Carl I'm using cairo 1.9.6, maybe that's relevant for this bug?
I'm seeing the bug on two i865 systems : Card:Intel 810 and later: Intel Corporation|82865G Integrated Graphics Controller [DISPLAY_VGA] (rev: 01) and Card:Intel 810 and later: Intel Corporation|82865G Integrated Graphics Controller [DISPLAY_VGA] (vendor:8086 device:2572 subv:1043 subd:80a5) (rev: 02) with driver 2.11.0 with xorg server 1.7.6 on mandriva cooker. It is with either cairo 1.9.6 or cairo 1.8.8 and either with pixman 0.18.0 or 0.16.2
A few recent patches pushed to master hook up the ShmPutImage to convert xrgb to argb. In particular: commit 2d17bd50af367bead84985c22fdd43d264a5f072 Author: Chris Wilson <chris@chris-wilson.co.uk> Date: Wed Apr 14 14:54:34 2010 +0100 Revert "Revert "uxa: Try using put_image when copying from a memory buffer."" This reverts commit 6d50553e8f70d8f2142efdfd6c90bc27a599d0bc. Now we have taught the fallback path not to infinitely recurse, re-enable the accelerated path for ShmPutImage and friends. And the subsequent patches to handle the failed pixman_blt. Does this fix/explain the corruption?
for the record, 2.11.0 + patches 1cc2c2c44ac72460cf1c4e6bdc13c612235809c9 27195d7dba0f3ff08b92f3fd916cdf5113cbef58 9a5cd65b593ea82e56e0c403f7ddcc2420a64dc3 8562b7bc6740eef2602af76b8685388efd2d4d37 does not fix the problem.
Tested lasted git-version of the intel-driver (Up to commit 0d4dd00aeafdd625ffe902e26e666b63a0842adc). Problem is still present on my 855GM-based notebook. Software : Xserver from Ubuntu 10.04, latest git libdrm and intel-driver.
I believe this should be fixed now.
Hi Chris, For me the bug is now fixed. No more false colors. I'm using the latest version (up to commit 58b089febceca1e915607bb723ee658aaa9dbed3) of the driver.
Thanks Stefan, I haven't had a chance to fire up my i845 to check.
Hi Chris, this is also fixed for me on master, but now menu highlighting results in a blank (no text) line *only when approaching from the south of the screen*. Plus, test-tfp (your ad-hoc performance test on a recente bug) has degraded terribly for me.
